About YKW85F-18A1 Precision Hollow Rotary Platform
The YKW85F-18A1 hollow rotary platform is engineered for precise, reliable motion control in advanced industrial automation settings. With a robust reduction ratio of 18:1, this platform delivers exceptional torque control, offering an allowable torque of 8 N.m, making it suitable for high-demand applications. It supports axial loads of up to 20 kg and radial forces of 10 N.m, enabling it to handle challenging industrial tasks with ease.
Capable of disk rotation speeds up to 720 per second, the YKW85F-18A1 ensures swift and efficient performance while maintaining precision. Its positioning accuracy is 1 arc-min, and it provides repetitive positioning accuracy of 10 arc-sec, allowing for accurate and consistent operations over extended periods. The platform boasts a long operational life, with an accuracy life exceeding 20,000 cycles, ensuring it meets the demands of rigorous, intermittent use.
This rotary platform is designed with a compact and durable IP40-rated housing, offering protection from dust and external particles. Weighing 1.2 kg, the YKW85F-18A1 is constructed for easy integration into various automation systems. Its hollow center allows for convenient cable management and flexibility in system design, making it an ideal choice for applications in robotics, assembly lines, and other automation processes requiring high-precision rotary motion.
| Model/Specification | YKW85F-18A1 |
| Allowable torque Nm | 8 |
| Allowable axial load (Ka)kg | 20 |
| Allowable radial force (Fr)Nm | 10 |
| Allowable disk Rotation speed | 720/sec |
| Reduction ratio i | 18 |
| Positioning accuracy | 1arc-min |
| Repetitive positioning accuracy | 10arc-sec |
| Accuracy life(intermittent operation) | 20000 |
| IP(Ingress Protection) | IP40 |
| Mass kg | 1.2 |
| Motor specification | A1:Integrated 42 open-loop stepper motor |
Versatile Precision for AutomationThe YKW85F-18A1 Hollow Rotary Platform is tailored for robotics and automation, delivering reliable rotational movement with high accuracy. Its bidirectional control supports multifaceted motion requirements in dynamic environments, ensuring optimal operational efficiency and ease of installation in diverse system configurations.
Superior Build and LongevityCrafted from premium stainless steel, this rotary platform is engineered for resilience and longevity. The material ensures robust mechanical performance while minimizing wear, making it suitable for demanding industrial environments and long-term use without compromising on performance.
FAQs of YKW85F-18A1 Precision Hollow Rotary Platform:
Q: How does the YKW85F-18A1 Precision Hollow Rotary Platform benefit robotics and automation systems?
A: The platform provides precise, bidirectional rotation, which enhances control and flexibility in robotics and automation applications. Its high efficiency and durable stainless steel construction ensure consistent performance and reduced maintenance costs over time.
Q: What is the process for integrating this rotary platform into existing systems?
A: Integration is straightforward due to the standard size and standardized interfaces. Follow the installation guidelines in the manual to ensure secure mounting and optimal connectivity with your drive mechanisms and control units.
Q: When is it recommended to use a hollow rotary platform instead of a traditional rotary table?
A: Use a hollow rotary platform like the YKW85F-18A1 when you need to route cables, fluids, or other elements directly through the axis, or when compact, high-precision, bidirectional rotation is essential for your application.
Q: Where can the YKW85F-18A1 be applied in automation environments?
A: This platform is ideally suited for use in robotics arms, automated assembly lines, inspection systems, and other machinery requiring accurate rotational movement within manufacturing and industrial automation sectors.
Q: What are the main benefits of the stainless steel build?
A: Stainless steel offers excellent resistance to corrosion, wear, and mechanical stress, ensuring durability and longevity even in harsh industrial settings, while maintaining precise operational standards.
Q: How does the 90% efficiency rating impact overall system performance?
A: A 90% efficiency rating means minimal energy loss during operation, resulting in better performance, reduced operational costs, and higher reliability for your automation or robotics system.
